VEST BAG & SHOPPING BAG TURNKEY PRODUCTION LINE
This machine is professionally used to producing t-shirt shopping bags (vest bag), adopt servo motor control, can easily adjust the length of the bag and the thickness of the bag. The unwind materials can be HDPE film, LDPE film as well as recycling film.
Independent dual-lane for doubled output. Magnetic-powder tension ensures uniform unwinding and anti-wrinkle thin film
Full servo drive, easy adjustment of bag size, stable performance and low failure rate
Supports HDPE, LDPE and recycled film, flexible for virgin & recycled materials
Combined hot-sealing & cutting, firm seal, clean edge and stable bag quality
Auto produce T-shirt bags, heat-sealing, cutting & punching in one step.
A/B servo guiding, separate-parameter adjustment for two films.
Servo & air-pipe control for automatic bag stacking.
Support various film thickness, adjustable bag length & width.
Magnetic-particle tension control for stable film feeding
| Category | Item | Specification |
|---|---|---|
| Machine Basic Info | Model | APB-500X2 |
| Bag-making Capacity | Max.Bag Width | 180-400mm ×2 channels |
| Max.Bag Length | 280-700mm | |
| Film Thickness | 0.008-0.03mm | |
| Production Speed | 300 pcs/min per channel | |
| Electrical Data | Total Power | 10KW |
| Power Supply | 3P、380V、50HZ | |
| Machine Dimension & Weight | (L×W×H) Overall Dimension | 7100×1800×1830 mm |
| Machine Weight | 2700kg |
Supermarkets, farmers' markets, convenience stores and small-commodity wholesale for shopping goods packaging.
Fresh fruits & vegetables, food takeaway; food-carrying hand-bag packaging.
Professional bag-making factories for large-volume mass-production orders.
Production of eco-friendly plastic bags with recycled materials.
